CT-124H 32DI DC Sink Source Module Kỹ thuật số ngõ ra 32 Kênh của ODOT

CT-124H 32DI DC Sink hoặc Source Module Kỹ thuật số ngõ ra 32 Kênh của ODOT, hỗ trợ chức năng đếm ( Tần số đếm lên đến 200Hz)

◆ the module supports 32 channels digital input, it supports sink input and the input high level is valid as it could support PNP sensor; it also supports source input and the input low level is valid as it could support NPN sensor.

◆ the module could collect the digital output signal of field equipment (dry contact or active output).

◆ the module could be connected to 2-wire or 3-wire digital sensor.

◆ the internal bus of the module and field input are isolated by optocoupler.

◆ the module supports input signal holding function, holding time can be set.

◆ after adding counting submodule in ODOT configured software, the counting function is effective.

◆ each input channel of the module supports 32-bit counter with counting frequency <200Hz.

◆ the module could be set the digital signal input filter time and counter byte transmission sequence.

◆ each channel of the module could be set the counting mode and counting direction independently
